美制JIC内螺纹74°内锥面

hotline service:
Specifications
代号 E 胶管 尺寸
螺纹 公称内径 标号 A C S
26711-04-04RW 7/16"X20 6 04 15 9 15
26711-05-05RW 1/2"X20 8 05 15.5 9.5 17
26711-06-05RW 9/16"X18 8 05 15.5 10.5 19
26711-06-06RW 9/16"X18 10 06 15.5 10.5 19
26711-06-08RW 9/16"X18 13 08 16 10.5 19
26711-08-06RW 3/4"X16 10 06 17.5 11 24
26711-08-08RW 3/4"X16 13 08 18 11 24
26711-10-08RW 7/8"X14 13 08 18.5 13 27
26711-10-10RW 7/8"X14 16 10 20 13 27
26711-10-12RW 7/8"X14 19 12 20 13 27
26711-12-10RW 1.1/16"X12 16 10 21.5 15 32
26711-12-12RW 1.1/16"X12 19 12 21.5 15 32
26711-14-12RW 1.3/16"X12 19 12 21.5 15 36
26711-16-16RW 1.5/16"X12 25 16 23 16 41
26711-20-20RW 1.5/8"X12 32 20 26 17 50
26711-24-24RW 1.7/8"X12 38 24 26.5 20 55
26711-32-32RW 1.7/8"X12 51 32 27 23.5 75
注:1表中代号用于编织软管。2、如需用于缠绕软管代号改为 S26712-XX-XXRW.
